NDR-5227-2RPM
Synchronous Motor
AC Synchronous Geared Motor
Technical Performances: | |
Rated Voltage | 220-240 VAC |
Rated Frequency | 50/60 Hz |
Eput Power | 4WMax. |
Output Speed | 2.0 RPM Constant |
Rated Torque | 12 KgNaN Min. |
Starting Voltage | 176V AC Max. |
Temperature Rise | 65K Max. |
Noise Level | 50dB(A)Max. |
Insulation Resistance | WOMOhm Min. |
Dielectric Strength | 1800VAC, 1S |
hKnosto^ | 1st Angle | Customer Name: | |||||||
Hill PROFESSIONAL MOTOR DESIGNER & MANUFACTURER | Contract No./Date: | ||||||||
Marks | No. | Amendment Contents | Signature | Date | Designed | T.Y.Wang | Drawing Marks | ||
The materials described and/or the information conveyed by this drawing and/or the relative documents are proprietary to Nostop Motor Group, are or may be the subject of patent applications, and may not be copied and divulged to others, or used for manufacturing without written consent by Nostop. | Corrected | T.Y.Wang | A 叩 lication: | ||||||
Checked | Dong, QIN | Weight | Scale | ||||||
Drawn | HERO | 0.19 Kgs | 1:1 | Produced By: Nostop Motor Gro叩(SZN) Factory | |||||
Total: 1of1 | Date: 2010-5-28 | ||||||||
