NSM-57TYZ Series
Synchronous Motor
* Special designed for oven and grill or other kitch appliances.
* Low noise, high torque, low operating temperature
* Nickel Steel Gears and Medium Carbon Steel Gears
| SRECIFICATIONS | |||||||
| RATED VOL TAGE | VAC | 220-240 | |||||
| RATED FREQUENCY | HZ | 50 OR 60 | |||||
| INPUT POWER | W | 4月6日 | |||||
| INPUT CURRENT | mA | <=35 | |||||
| OUTPUT SPEED (AT 50HZ) | RPM | 1.5 | 2 | 2.3 | 2.5 | ||
| OUTPUT TOPQUE (AT 50HZ) | Kgf.cm | 16 | 14 | 12 | 11 | ||
| NOISE | DB(A) | <=45 | |||||
| INSULATION RESISTANCE | mΩ | >100 | |||||
| INSULATION CLASS | E | ||||||
| CIELECTRIC STRENGTH | AC1500V 50Hz/min | ||||||
| ROTATION DIRECTION | FREE | ||||||
| OPERATION VOL TAGE CAN BE CHQANGED AS USER"S DEMAND | |||||||
