NSR110 Series
Synchronous Motor
Main aplication :
Mainly used for Autoamtic Curtains, Stage Lights, Electric Andvertisement, Electric Appliances,Pumps, Scientific Mainly used for Autoamtic Curtains, Stage Lights, Electric Andvertisement, Electric Appliances,Pumps, Scientific
Standart Parforamances (test under room temperature):
| Rated Volt. | Rated Freq'y | Output Speed | Input Current | Input Power | Max. Torque | Rated Torque | Start Torque | Capacitor | G.W. | ||
| Model | Ph. | (VAC) | (Hz) | (rpm) | (A) | (W) | (Nm) | (Nm) | (Nm) | (μF/V) | (Kgs) |
| NSR110-060-5 | 1 | 220 | 50 | 60 | 0.5 | 90 | 5.5 | 5 | 2 | T9.2/400 | 6 |
| NSR110-060 | 1 | 220 | 50 | 60 | 0.55 | 110 | 6 | 5.6 | 2.7 | 4.0/400 | 6 |
| NSR110-060-2 | 3 | 220 | 50 | 60 | 0.65 | 120 | 7.5 | 7 | 3.5 | 6 | |
| NSR110-060-3 | 3 | 380 | 50 | 60 | 0.38 | 120 | 7.5 | 7 | 3.5 | 6 | |
| NSR110-115-5 | 1 | 220 | 50 | 115 | 0.6 | 110 | 3.8 | 3.4 | 1.6 | T9.8/400 | 6 |
| NSR110-115 | 1 | 220 | 50 | 115 | 0.6 | 110 | 4 | 3.6 | 1.7 | 4.0/400 | 6 |
| NSR110-115-2 | 3 | 220 | 50 | 115 | 0.7 | 130 | 6 | 5.4 | 2.7 | 6 | |
| NSR110-115-3 | 3 | 380 | 50 | 115 | 0.4 | 130 | 6 | 5.4 | 2.7 | 6 |
